• Compact barrel grip for easy handling
• Electronic current limiter with warning lamp protects motor from overloading / over-heating
• Compact and ergonomic design at only 317mm long
• Lightweight for reduced operator fatigue
• Soft grip provides increased comfort on the job
• Spiral bevel gears for smoother rotations and a more efficient transfer of energy
• Anti-restart function with warning lamp engineered to minimize motor start up when battery is inserted with switch locked on
• Battery protection circuit protects against overloading, over-discharging and over-heating
• Side handle can be installed on either side of the tool for operator convenience
• Wheel cover protects operator from accidental scattering of broken wheel or workpiece with minimal wheel cover movement
• Spindle lock for easy wheel changes
• Externally accessible brushes for easy serviceability
Buy From Retailer
| Wheel diameter | 115 mm (4-1/2″) |
| No load speed | 8,500 minˉ¹ |
| Abrasive cut-off wheel diameter | 115 mm (4-1/2″) |
| Abrasive grinding wheel diameter | 115 mm (4-1/2″) |
| Diamond wheel diameter | 115 mm (4-1/2″) |
| Brush diameter capacity | 115 mm (4-1/2″) |
| Cup brush diameter capacity | 75 mm (3″) |
| Disc paper diameter | 115 mm (4-1/2″) |
| Max abrasive wheel thickness | 6.4 mm (1/4″) |
| Hole diameter | 22.23 mm (7/8″) |
| Rubber pad diameter | 100 mm (4″) |
| Thread | M14x2.0 |
| Vibration level | Surface grinding w/ Anti-vibration side grip: 6 m/s² Surface grinding w/ Normal side grip: 6.5 m/s² Disc sanding w/ Anti-vibration side grip: 2.5 m/s² or less Disc sanding w/ Normal side grip: 2.5 m/s² or less |
| Vibration K factor | Surface grinding w/ Anti-vibration side grip: 1.5 m/s² Surface grinding w/ Normal side grip: 1.5 m/s² Disc sanding w/ Anti-vibration side grip: 1.5 m/s² Disc sanding w/ Normal side grip: 1.5 m/s² |
| Sound pressure level | 79 dB(A) |
| Sound power level | N/A dB(A) |
| Noise K factor | 3 dB(A) |
| Dimensions (L x W x H) | 362 x 130 x 151 mm (14-1/4 x 5-1/8 x 5-15/16″) |
| Net weight | 2.34–3.03 kg (5.17–6.67 lbs.) |
