• Increased max clutch torque enables to adjust clutch torque even when tightening
fasteners into hard material
• Compact and ergonomic design at only 178 mm long
• 0-31,500 IPM for fast hammer drilling in masonry materials
• BL motor delivers 141 N·m of max torque
• BL motor is electronically controlled to optimize battery energy use for longer run time per charge
• BL motor eliminates carbon brushes, enabling the BL motor to run cooler and more efficiently for longer life
• All metal variable 2-speed transmission (0-550 & 0-2,100 RPM) for a wide range of drilling, fastening and hammer drilling applications
• All metal gears and gear housing for maximum job site durability
• All metal 13 mm self ratcheting chuck for improved bit gripping strength and durability
• Lightweight for reduced operator fatigue
• 21 clutch settings and drill mode for added fastening control
• 3-stage LED gauge indicates battery charge level
• Water-resistance compatible with XPT
• Twin LED lights with afterglow feature illuminate the work area
• Electric brake for maximum productivity
• Reverse switch is conveniently located
• Keyless chuck for quick and easy bit installation and removal
• Depth gauge for increased drilling consistency.
Durable, reversible belt clip convenient for temporary tool hanging.
Battery protection circuit protects against overloading, over-discharging and over-heating
| No load speed | High: 0 – 2,100 minˉ¹ | Low: 0 – 550 minˉ¹ |
|---|---|---|
| Impacts per minute | High: 0 – 31,500 minˉ¹ | |
| Capacity | Masonry: 16 mm (5/8″) Wood (Auger-bit): 50 mm (2″) Hole saw: 152 mm (6″) Flat bit: 40 mm (1-9/16″) Ship auger: 38 mm (1-1/2″) Forstner drill bit: 50 mm (2″) Multi-siding core bit: 170 mm (6-11/16″) Glass: 12 mm (15/32″) |
Steel: 13 mm (1/2″) Wood (Self-feed bit): 76 mm (2″) Wood (Drill bit): 20 mm (13/16″) Single spur auger bit: 50 mm (2″) Formwork: 30 mm (1-3/16″) Adjustable circle: 200 mm (7-7/8″) Step/cone drill: 35 mm (1-3/8″) Brush / flap wheel: 100 mm (3-15/16″) |
| Max torque | 141 N·m (1,250 in.lbs) | |
| Max fastening torque | Hard: 130 N·m (1,150 in.lbs.) | Soft: 65 N·m (580 in.lbs.) |
| Chuck capacity | 1.5 – 13 mm (1/16 – 1/2″) | |
| Max output | 680 W | |
| Vibration level | Impact drilling into concrete: 8.6 m/s² | Drilling into metal: 2.5 m/s² or less |
| Vibration K factor | Impact drilling into concrete: 1.5 m/s² | Drilling into metal: 1.5 m/s² |
| Sound pressure level | 87 dB(A) | |
| Sound power level | 95 dB(A) | |
| Noise K factor | 3 dB(A) | |
| Dimensions (L × W × H) | w/ BL1830B / BL1850B / BL1860B: 180 x 81 x 265 mm (7-1/8 x 3-3/16 x 10-3/8″) w/o Battery: 180 x 81 x 217 mm (7-1/8 x 3-3/16 x 8-1/2″) |
|
| Net weight | 2.3 – 2.7 kg (5.1 – 6.0 lbs.) | Battery Dependent |
