DHS680ZJ Cordless Circular Saw

Download HR Image

Download Exploded View

PRODUCT DETAIL

• Compact angle head with small head height
• LED job light with afterglow function
• Ergonomically designed rubberized soft grip
• Easy-to-operate large paddle switch trigger
• On-tool chuck key storage for fast and convenient bit changes
• Sturdy aluminium gear housing
Compact and lightweight design





No load speed 5,000 minˉ¹
Blade body thickness 1.0 mm
Bevel range 0 – 50°
Max cutting capacity 0°: 57 mm (2-1/4″)
50°: 37 mm (1-7/16″)
45°: 41 mm (1-5/8″)
Saw blade position Left side
Material Base plate: Magnesium diecast
Blade case: Magnesium diecast
Safety cover: Magnesium diecast
Vibration level Cutting wood: 2.5 m/s² or less
Vibration K factor Cutting wood: 1.5 m/s²
Sound pressure level 83 dB(A)
Sound power level 94 dB(A)
Noise K factor 3 dB(A)
Dimensions (L × W × H) 350 x 170 x 238 mm (13-3/4 x 6-11/16 x 9-3/8″)
Net weight 3.0 – 3.3 kg (6.6 – 7.3 lbs.) Battery dependent
