• Jaw Case Designed to Enable Tight Space Operation
• Short centre height allows for tight space operation such as close-to-wall riveting
• Compatible with various sizes of blind rivets
• A wide range of nose pieces and jaw pushers allow for tightening various sizes of blind rivets
• Compatible rivet diameter: ø4.8mm, ø6.0mm, ø6.4mm
• High speed tightening
• Rivet holding mechanism: Once a rivet is installed, it is held in place and does not drop out even when the tool directed is downward
• Transparent mandrel container: The amount of spent mandrels can be checked
• BL motor delivers 20 kN of max pulling force
• BL motor eliminates carbon brushes, enabling the BL motor to run cooler and more efficiently for longer life
• Twin LED job light with pre-glow and afterglow functions illuminates the work area
• Electric brake for maximum productivity
• Water-resistance compatible with XPT
• Battery protection circuit protects against overloading, over-discharging and over-heating
Buy From Retailer
| Pulling force | 20 kN (4,500 lbs.) | |
|---|---|---|
| Stroke | 30 mm (1-3/16″) | |
| Rivet diameter range | 2.4 – 6.4 mm (3/32 – 1/4″) | |
| Center height | 26 mm (1″) | |
| Work amount | w/ BL1860B: 1,900 pcs | w/ BL1850B: 1,600 pcs |
| Max output | 360 W | |
| Vibration level | Installing blind rivet: 2.5 m/s² or less | |
| Vibration K factor | Installing blind rivet: 1.5 m/s² | |
| Sound pressure level | 74 dB(A) | |
| Noise K factor | 3 dB(A) | |
| Dimensions (L × W × H) | w/ BL1830B / BL1850B / BL1860B: 323 x 80 x 287 mm (12-3/4 x 3-1/8 x 11-1/4″) | |
| Net weight | 2.1 – 2.4 kg (4.6 – 5.3 lbs.) | Battery dependent |
