| Shank / Drive | Square Drive 12.7 mm (1/2″) | |
|---|---|---|
| Square drive | 12.7 mm (1/2″) | |
| Max fastening torque | 330 N·m (240 ft.lbs.) | |
| Fastening capacities | Standard bolt: M10 – M20 (3/8 – 3/4″) | High strength bolt: M10 – M16 (3/8 – 5/8″) |
| Nut-busting torque | 580 N·m (430 ft.lbs.) | |
| Automatic impact stop system | Yes | |
| No load speed | Max / Hard / Med. / Soft: 0 – 3,200 / 0 – 2,600 / 0 – 1,800 / 0 – 1,000 minˉ¹ | |
| Impacts per minute | Max / Hard / Med. / Soft: 0 – 4,000 / 0 – 3,400 / 0 – 2,600 / 0 – 1,800 minˉ¹ | |
| Max output | 420 W | |
| Vibration level | Impact tightening of fasteners of the maximum capacity of the tool: 12.5 m/s² | |
| Vibration K factor | Impact tightening of fasteners of the maximum capacity of the tool: 1.5 m/s² | |
| Sound pressure level | 97 dB(A) | |
| Sound power level | 108 dB(A) | |
| Noise K factor | 3 dB(A) | |
| Dimensions (L × W × H) | 144 x 81 x 246 mm (5-5/8 x 3-3/16 x 9-11/16″) | |
| Net weight | 1.8 kg (4.0 lbs.) | |
